Advantech ARK-1550 User Manual

vii ARK-1550 User Manual
18. CAUTION: The computer is provided with a battery-powered real-time clock cir-
cuit. There is a danger of explosion if battery is incorrectly replaced. Replace
only with same or equivalent type recommended by the manufacture. Discard
used batteries according to the manufacturers instructions.
ATTENTION: L'ordinateur est muni d'un circuit en temps réel de l'horloge ali-
mentée par batterie. Il ya un danger d'explosion si la pile est remplacée de
fa
çon incorrecte. Remplacez uniquement par un type identique ou équivalent
recommandé par le fabricant. Jetez les piles usagées selon les instructions du
fabricant.
19. CAUTION: Always completely disconnect the power cord from your chassis
whenever you work with the hardware. Do not make connections while the
power is on. Sensitive electronic components can be damaged by sudden
power surges.
ATTENTION: L'ordinateur est muni d'un circuit en temps réel de l'horloge ali-
mentée par batterie. Il ya un danger d'explosion si la pile est remplacée de
fa
çon incorrecte. Remplacez uniquement par un type identique ou équivalent
recommandé par le fabricant. Jetez les piles usagées selon les instructions du
fabricant.
The sound pressure level at the operator's position according to IEC 704-1:1982 is
no more than 70 dB (A).
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
Packing List
Before installation, please ensure the following items have been shipped:
 1 x ARK-1550 Unit
 1 x China RoHS
 1 x Chinese User Manual for CCC
 1 x Warranty Card
 1 x Power Bracket
 1 x CPU Thermal Pad
Ordering Information
Model Number Description
ARK-1550-S6A1E Intel Celeron DC 2980U 1.6 GHz w/HDMI+LAN+GPIO
ARK-1550-S9A1E Intel Core i5 DC 4300U 1.9 GHz w/HDMI+LAN+GPIO

Advantech ARK-1550 Specifications

General

Chassis type	-
Product color	Black, Silver
Water cooling system	No
Bus type	DMI2
Stepping	D0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-4300U
System bus rate	5 GT/s
Processor family	4th gen Intel® Core™ i5
Processor series	Intel Core i5-4300 Mobile series
Processor socket	BGA 1168
Processor threads	4
Processor codename	Haswell
Processor frequency	1.9 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Conflict-Free processor	Yes
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.9 GHz
Processor operating modes	64-bit
PCI Express configurations	4x1, 2x4
Thermal Design Power (TDP)	15 W
Number of processors installed	1
Maximum number of PCI Express lanes	12
Memory types supported by processor	DDR3L-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	16 GB
Certification	CE/FCC Class A, CCC, BSMI, UL, CCC, BSMI, CB
Memory slots	1x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Memory layout (slots x size)	1 x 8 GB
HDD size	2.5 \
HDD interface	SATA
Total storage capacity	0 GB
Serial ports quantity	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity	0
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Compatible operating systems	Windows 7, 8 Linux
On-board graphics card ID	0xA16
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4400
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	200 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Cover material	Aluminum
BIOS type	UEFI AMI
Audio system	HD
Product type	Embedded PC
Motherboard southbridge	Intel ICH8M
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 95 %
Power supply input voltage	12 V
Processor code	SR1ED
Processor ARK ID	76308
Intel TSX-NI version	0.00
Processor package size	40 mm
Intel ME Firmware Version	9.5
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Smart Connect Technology version	1.00

Weight and Dimensions

Depth	133 mm
Width	223 mm
Height	46.6 mm
Weight	- g
