EKI-6233BN User Manual 7
2.1.2 Rear View
Figure 2.2 Rear View
2.1.3 Top View
Figure 2.3 Top View
No. Item Description
1.
DIN-Rail mounting
plate
Mounting plate used for the installation to a standard DIN rail
1
No. Item Description
1.
Terminal block Connect cabling for power and alarm wiring
2.
Ground terminal Screw terminal used to ground chassis
P-Fail
V1 -
PWR1
V1 + V2 -
PWR2
V2 +
1 2
