Advantech MIO-5250 User Manual

MIO-5250 User Manual 2
1.1 Introduction
 CPU: Intel Atom
– N2600 (Dual Core 1.6GHz) on MIO-5250N-S6A1E
– D2700 (Dual Core 2.13GHz) on MIO-5250D-U1A1E
 MI/O Compact SBC form factor standard
 One 204-pin SODIMM DDR3 up to 4G
– N2600: DDR3 800 MHz
– D2700: DDR3 1066 MHz
 Dual Independent Display: VGA+LVDS, VGA+HDMI, HDMI+LVDS
 6 x USB 2.0 ports
 1 x SATAII (Max data transfer rate 300 MB/s)
 4 x COM (2 x RS-232, 2 x RS-232/422/485)
 Multi level Watchdog timer (set by Advantech iManager)
 2 x GbE
 MIOe connector
1.2 Product Specifications
General
I/O
CPU
CPU: Intel Atom
- N2600 (Dual Core 1.6GHz) on MIO-5250N-S6A1E
- D2700 (Dual Core 2.13GHz) on MIO-5250D-U1A1E
L2 Cache
N2600: 1MB
D2700: 1MB
System Chipset Intel Atom N2600 / D2700 + NM10
BIOS AMI EFI 16-Mbit
System Memory
1 x 204-pin SODIMM socket DDR3 up to 4GB:
N2600: up to DDR3 800
D2700: up to DDR3 1066
Power Management APM1.2, ACPI support
SSD mSATA (Full-size Mini PCIe interface), CFast
Watchdog Timer
255 levels timer interval, programmable by software. Multi level WDT
(set by iManager)
Expansion Interface Full-size Mini PCIe, CFast, SIM Holder, MIOe
Battery Lithium 3 V / 210 mAH
Internal I/O Interface
1 x SATAII, 2 x RS-232, 2 x RS232/422/485, 2 x USB 2.0, GPIO,
SMBus, HD Audio
Rear I/O 4 x USB 2.0, HDMI, VGA, 2 x RJ45 Ethernet, Power connector
Power Connector
Type
MIO-5250N-S6A1E: DC Jack
MIO-5250D-U1A1E: 2 x 2 pin Power connector
SMBus Supported
GPIO 8-bit general purpose input/output

Advantech MIO-5250 Specifications

General

Brand	Advantech
Model	MIO-5250
Category	Motherboard
Language	English
