MIO-5250 User Manual vi
Optional MIOe Module
*MIOe-230 compatibility is optional by request (need BOM update).
Optional Accessories
Safety Instructions
1. Read these safety instructions carefully.
2. Keep this User Manual for later reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth. Do not use liquid or spray detergents for cleaning.
4. For plug-in equipment, the power outlet socket must be located near the equip-
ment and must be easily accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during installation. Dropping it or letting
it fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. DO NOT COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
9. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
12. Never pour any liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
Part Number Description
MIOe-210-D6A1E
4x RS232/422/485 2x RS422/485 with DSUB connector, 8-bit
GPIO
MIOe-220-B3A1E 3 x GbE with RJ45 connector through PCIe switch
MIOe-230-L0A1E* Displayport to 48-bit LVDS
M I O e - D B 5 0 0 0 - 0 1 A 1 E * M I/O extension evaluation board w/ PCIe switch
Part number Description
1960054269T001 Heat spreader 137x84.2x16.7-mm MIO-5250
1703100260 Internal USB 5/6 cable
1935032000 Screw of Heatsink / Cooler R/S 5.5 2.0 +M M3*20L ST Ni
1930000058 The POST Stand off, F=M3*8L M=M3*4L D=5 H=19L Cu
1757003062 ADAPTER 100-240V 60W 12V 5A W/O PFC
To Next Page
