Advantech MIO-5250 User Manual

3 MIO-5250 User Manual
Chapter 1 General Information
Ethernet
Display
1.3 Chipset
1.3.1 Functional Specifications
1.3.1.1 Processor: Intel Atom N2600/D2700
Speed GbE 10/100/1000 Mbps
Chipset Intel 82583V (GbE1, GbE2)
Ethernet Interface Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Connector RJ45 x2
Wake On Function Wake-on-LAN
Controller Intel Atom N2600 / D2700
Resolution
 VGA: N2600 / D2700: 1920 x 1200
 LVDS:
N2600: 24-bit LVDS1, resolution up to1366 x 768
D2700: 24-bit LVDS1, resolution up to 1440 x 900,
48-bit LVDS2 (JEIDA support), resolution up to 2560 x
1600
 HDMI:
Supports 1920 x 1200p @60Hz, 36bpp
Supports HDMI 1.3, Max data rate up to 1.65Gb/s
Dual Independent Display VGA+LVDS, VGA+HDMI, HDMI+LVDS
CPU Process 32nm
Frequency
- N2600: 1.6GHz
- D2700: 2.13GHz
Memory
SO-DIMM DDR3 up to 4G
- N2600: DDR3 800 MHz
- D2700: DDR3 1066 MHz
VGA Memory Up to 512MB of dynamic video memory allocation
Internal Graphics Features
 DirectX® 9 and OpenGL 3.0
 Display Port 1.1, HDMI 1.3a
 Supports HDCP 1.3
 Intel Display Power saving technology 6.0
 SGXS45 Power VR Core 400/640 MHz
Video Accelerator
 H/W accelerated video decode
 Video decoder: Support MPEG4, VC1, WMV9, H.264
 Supports DVD, Blu-ray, and HD video
Display
 VGA: N2600 / D2700: 1920 x 1200
 LVDS:
N2600: 24-bit LVDS1, resolution up to1366 x 768
D2700: 24-bit LVDS1, resolution up to 1440 x 900,
48-bit LVDS2
 HDMI:
Supports 1920 x 1200p @60Hz, 36bpp
Supports HDMI 1.3, Max data rate up to 1.65Gb/s
Dual independent display VGA+LVDS, VGA+HDMI, HDMI+LVDS
