Advantech MIO-5250 User Manual

5 MIO-5250 User Manual
Chapter 1 General Information
1.3.2 Mechanical Specifications
1.3.2.1 Dimensions (mm)
146 x 102 mm (5.7 x 4 inches)
1.3.2.2 Board height on Top side (mm)
16,4mm (Rear I/O USB)
1.3.2.3 Board height on bottom side (mm)
9mm (Full-size Mini PCIe socket)
1.3.2.4 Heatsink/Cooler Dimensions (mm)
137mm (L) x 87.2mm (W) x 25mm (H)
1.3.2.5 Board net weight without heatsink (g)
140 g
1.3.3 Electrical Specifications
1.3.3.1 Power Supply Voltage
 Power Type
Single 12V DC power in
 Power Supply Voltage
Single 12V ± 10%
1.3.3.2 Power Consumption
Test Condition:
 Add-in Card - None
 Full-size Mini PCIe - None
 Memory - DDR3 SODIMM 4GB
 HDD - 3.5" WD 80GB SATA2 *1
 KeyBoard/Mouse - USB
 Display - VGA
1.3.3.3 RTC Battery
 Typical Voltage: 3.0 V
 Normal discharge capacity: 210 mAh
Condition
Power Consumption (A)
Voltage/
Condition
DOS Idle
Mode
Win. Idle
Mode
Win. HCT12
(10minutes)
S3 mode S5 mode
MIO-5250N-S6A1E +12V 0.606 0.524 0.729 0.049 0.041
MIO-5250D-U1A1E +12V 0.891 0.751 1.056 0.049 0.041
