MIO-5250 User Manual 4
1.3.1.2 Chipset (NM10)
1.3.1.3 iManager
1.3.1.4 Others
South Bridge
Control Hub NM10
RS-232 2
RS-232/422/485 2
K/B 1
Mouse 1
USB 6 x USB 2.0
Audio
HD Audio, ALC892 Codec, Line-in, Line-out, Mic-in, speaker out (R/L)
(Supports 8
Ω 1W or 4Ω 2 W Speaker for Speaker-out)
Other Features
* 6 x USB 2.0 ports, 480MB/s (all internal connectors)
Default: 500mA @ one port (Up to 1A @ 2 ports)
* 1 x SATAII (Max. Data transfer Rate 300MB/s)
* HD Audio CODEC (ALC892)
* Power Management (S0, S3,S4, S5)
BIOS 16-Mbit Flash BIOS via SPI
iManager
Sequence control Supported
SMBus Supported
GPIO 8-bit GPIO
Watchdog timer
Multi Level WDT (set by Advantech iManager)
Programmable 1-255 sec / min
Hardware monitor CPU Temperature / input Current / input Voltage
Power saving Deep sleep S5 mode / Smart Fan / Back light control
FAN
1. Smart FAN Support.
2. Programmable automatic fan monitor based on temperature.
3. Reserve System FAN Power Connector x 1
Pin2: +12 V
Pin3: Fan speed signal input
Board information Running HR / Boot record
Storage Read / Write data protection
VGA Low Level Backlight / Brightness control
Ethernet
Chipset Intel 82583V (GbE1, GbE2)
IEEE Compliant Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Disable LAN through
BIOS
Yes
Driver Support WES7
Audio
Codec HD Audio, Realtek ALC892
Connector Line in, Line out, Mic in, Speak out (R/L, 8 Ohm 1W/4Ohm 2W)
Voltage +3.3V, +5V, +12V, Vcore
