39
MIO-5250 User Manual
Appendix A
Pin Assignments
PC13
+3.3V
PC14
+3.3V
PC15
GND
PC16
GND
PC17
CDO
S1
GND
S2
TX+
S3
TX-
S4
GND
S5
RX-
S6
RX+
S7
GND
CN12
SIM
Part Number
1654000639
Footprint
SIM-WL608C
Description
SIM card conn 6p 90D(F)
SMD WO/Pb WL608C3-M04-7
F
Pin
Pin Name
1U
I
M
_
P
W
R
2
UIM_RESET
3
UIM_CLK
4G
N
D
5U
I
M
_
V
P
P
6U
I
M
_
D
A
T
A
48
50
