Advantech SPC-815 - Page 42

SPC-800(M) User Manual 32
 Freely configuration do it by yourself assembly
 Terminal Board PIN Define
 Push Button of Type
Description Picture
RAFIX 22 FS+ - Emergency stop pushbutton, not illuminable, reset by
rotation, red arrows
1.30.273.511/0300
RAFIX 22 FS+ - Pushbutton, illuminated, flush lens, round collar,
metal front ring, momentary
1.30.270.021/2200
RAFIX 22 FS+ - Drucktaster nicht beleuchtbar , flache Blende,
Bund rund, Frontring Metall, tastend
1.30.270.021/0100
RAFIX 22 FS+ - Pushbutton, illuminated, flush lens, round collar,
metal front ring, momentary
1.30.270.021/2600
RAFIX 22 FS+- Pushbutton, illuminated, flush lens, round
collar, metal front ring, momentary
1.30.270.021/2300
RAFIX 22 FS+- Pushbutton, illuminated, flush lens, round
collar, metal front ring, momentary
1.30.270.021/2500
