3 UNO-2372G User Manual
Chapter 1 Overview
1.3 Accessories
The accessory list is as follows:
1 x pin connector for power wiring (Advantech P/N: 1652002205)
1 x warranty card
1 x SATA cable (Advantech P/N:1700027329-11)
4 x screws for attaching HDD (Advantech P/N:1930001361)
2 x screws for attaching mPCIe module (Advantech P/N:1930000198)
If any of the above items are missing or damaged, contact your distributor or sales
representative immediately.
1.4 Hardware Specifications
Operating Temperature: -20 ~ 60 °C/-4 ~ 140 °F
Power Requirements: 10 - 36 V
DC
Power Consumption: 30 W (typical), 42 W (max.)
System Hardware:
– CPU:
UNO-2372G-E0 series: Intel® Atom™ E3845 (1.91 GHz)
UNO-2372G-J0 series: Intel® Celeron® J1900 (2.0 GHz)
– Memory: 4 GB of DDR3L 1600 MHz (up to 8 GB)
– Graphics Engine: Intel® HD Graphics
– Ethernet: Intel® i210 GbE, 802.10av, IEEE1588/802.1AS, 803.3az
– COM: 4 x RS232/422/485
– USB: 4 x USB (3 x USB 2.0, 1 x USB 3.0)
– Storage:
1 x full-size mSATA slot (shared with 1 x mPCIe slot)
1 x drive bay for SATA 2.5" HDD (compatible with an HDD height of 9.5 mm)
– Expansion: 2 x full-size mPCIe slots (1 x mPCIe also supports mSATA)
– Display: 1 x DP with 2560 x 1440 resolution @60 Hz and 1 x HDMI with
1920 x 1080 resolution @ 60 Hz
– Hardware Security: TPM2.0 (UNO-2372G-J series only)
Because UNO-2372G features a modularized design, Advantech offers both single-
and double-stack models.
* Single stack: UNO-2372G-E021AE/UNO-2372G-J021AE
* Double stack: UNO-2372G-E022AE/UNO-2372G-J022AE
The double-stack model combines a single-stack model with an extension kit for
iDoor technology.
