Advantech UTC-315 User Manual

31 UTC-315 User Manual
Appendix A I/O Pin Assignments
Table A.9: MINIPCIE1:MINIPCIE
Part Number 1654002538
Footprint FOX_AS0B226-S68K7F
Description MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H
Pin Pin name
1 MPCIE1_WAKE#
2 +3.3VSB
3NC
4GND
5NC
6NC
7 MPCIE_CLKREQ#
8NC
9GND
10 NC
11 CLK_MINI_PCIE-
12 NC
13 CLK_MINI_PCI+
14 NC
15 GND
16 NC
17 NC
18 GND
19 NC
20 MPCIE1_DISABLE#
21 GND
22 PLTRST#
23 PCIE_RX-
24 +3.3VSB
25 PCIE_RX+
26 GND
27 GND
28 +1.5V
29 GND
30 SMB_CLK_MPCIE1
31 PCIE_TX-
32 SMB_DAT_MPCIE1
33 PCIE_TX+
34 GND
35 GND
36 USB_D-
37 GND
38 USB_D+
39 +3.3VSB
40 GND
41 +3.3VSB
42 NC
