Newswift 90-180 Motorised Antenna 33
Set Feed Position
Command: SFPx
Response: FPx
x Feed Position 1: Feed position 1
2: Feed position 2.
FPx response coded as above.
Query Monitoring Voltages
Command: QMV
Response: MV±aaa±bbb±ccc±ddd±eee±fff±ggg±hhh±iii±jjj±kkk±lll
±aaa 36V motor supply. Units 0.1V.
±bbb 12V electronics supply. Units 0.1V.
±ccc 5V MRD supply. Units 0.1V.
±ddd 12V Inclinometer supply. Units 0.1V.
±eee 12V Stow sensors supply. Units 0.1V.
±fff 15V Waveguide switch supply. Units 0.1V.
±ggg 12V brake drive supply. Units 0.1V.
±hhh Variable heatsink fan supply. Units 0.1V.
±iii DCU5000 : 12V compass supply. Units 0.1V
iACU/DCU4000: 12V feed supply. Units 0.1V.
±jjj DCU5000: 5 or 12V GPS supply. Units 0.1V.
iACU/DCU4000: 12V external GPS/Compass supply. Units 0.1V.
±kkk 12V external status supply. Units 0.1V.
±lll Motor current.
(
Units. 0.1A
)
Query Monitoring Temperatures
Command: QMT
Response: MT±aaaa±bbbb±cccc±dddd±eeee±ffff
±aaaa Internal ambient temperature. Units 0.1°C.
±bbbb Heatsink fin 1 temperature. Units 0.1°C.
±cccc Heatsink fin 2 temperature. Units 0.1°C.
±dddd Heatsink fin 3 temperature. Units 0.1°C.
±eeee Heatsink fin 4 temperature. Units 0.1°C.
±ffff Heatsink fin 5 temperature. Units 0.1°C.
----- Fin not fitted.
