Section I- Product Introduction
7
Electrode pads.
Composition: Composed of two
electrodes
Type: Non-rechargeable Lithium-ion
battery
- DC 21V (1,400mAh)
- DC 9V (1,400mAh)
Detachable
Type Cartridge
(Separate
Battery and
Electrode Pads)
Type: Non-chargeable Lithium-ion battery
- DC 21V (1,400mAh)
- DC 9V (1,400mAh)
The number of defibrillation shock can be marked on
the cartridge.
Only a detachable type electrode pads can be used.
Size: 150(W) X 110(L) X 33(H)mm
Warranty: About five (5) years (Sealed storage at
room temperature)
Detachable
Type Electrode
Pads
Disposable
Area: 86.44cm
2
(Hydro Gel)
Wire length: 2m±20%
Attachment point shown in pictures on electrode pads.
Composed of two (2) electrodes attached to pads
Warranty: About two (2) Years
Voice prompts for operational use for both instances
where ventricular defibrillation is required or should be
bypassed.
Voice prompts of all procedures for providing first aid
to the patient.
Voice prompts for the self-test result.
