5-1. All-in-one type cartridge
Pull the protruding edge of the film at the edge of
the cartridge.
Completely remove the cartridge cover film.
5-2. Detachable type electrode pads
Take out the electrode pads from the separate
electrode pads storage envelope and then remove
the protective lining.
Ensure to check if the electrode pads connector is
connected to the separate cartridge.
6. Place one pad on the patient’s bare skin as
shown in the picture. Press the adhesive portion of
the pad down firmly. Be sure to follow the same
instructions for the other pad.
(※ The position of the electrode pad attachment is critical
for proper use.)
Voice prompt: “Inspect pad placement area, then
adhere pad.”
Lamp state – Before attaching electrode pads:
Electrode pads attachment pad lamp ( ) flickers.
After correct attachment of electrode pads:
Electrode pads attachment pad lamp ( ) will
be ON.
