Section II – Product Use
26
For women, as seen in the picture,
check the placement for attaching
electrode pads and put them on the
patient’s body tightly. The placement
of both pads is generally the same
as the placement for men, but make
sure the left pads (LL) are placed
below the left breast (not on top).
(※ The position of the electrode pad
attachment is critical.)
7. Keep away from the patient according to the voice
from the product.
Voice prompt: “Stay clear of patient”
User must stay clear of the patient and the
HeartPlus™ device during analysis of patient's
state.
8. HeartPlus™ analyzes the electrocardiogram.
Voice prompt: “still diagnosing.”
Lamps to indicate the operation state: Lamp to
indicate the attachment of an electrode pad
( ) is lit and the electrocardiogram analysis lamp
( ) flashes.
After the analysis of electrocardiogram (ECG) is
complete, ECG analysis lamp is already ON.
