Section II – Product Use
30
4. Press PUSH on the cartridge cover to raise the
cover.
5-1. All-in-one cartridge
After you pull out the arrow portion on the
cartridge protective film and then remove film, take
out the electrode pads. Remove the protective film
on the electrode pads.
5-2. Detachable type electrode pad
Take out the electrode pads from the separate
electrode pads storage envelope and then remove
the protective film.
Ensure to check if the electrode pads connector is
connected to the separate cartridge.
6. Place the pad on the patient’s bare skin exactly
as shown in the picture. Press the adhesive portion
of the pad down firmly. Then repeat this with the
other pad (※ The position of the electrode pad
attachment is critical.)
Voice prompt: “Inspect pad placement area,
then adhere pad.”
Lamp state: Before attaching electrode pads:
Electrode pad attachment lamp ( ) flickers.
After correct attachment of electrode pad:
Electrode pad attachment pad lamp ( )
will be ON.
To Next Page
