This is a complete listing of available PIDs. An AEM supplied setup file for OBDII messages will be located in the

\Documents\AEM\DashDesign\Setups\Generic folder. The basic default OBDII file is named Default-Black-

OBD2.aemcd7.

Complete PID list will vary between cars so modification to the default setup is encouraged to view desirable data.

Note: Any PID not logged or displayed on the setup will not be used or active while car is running. To better view

important data, increase request rate and remove unnecessary PIDs from setup.

Editing Display Setups

The display setup file has the extension .aemcd7 and contains all the information needed to configure a color display

including connection definition, sensor calibration and screen layout.

Opening and Saving Setups

To Open an existing color display setup:

Select File | Open.... The file open dialog is shown.

Select the required display setup file and click Open.

The last five files opened can be accessed by selecting File | Reopen followed by the appropriate file from the sub

menu.

To save a setup under a new filename, select File | Save As...., enter a file name in the file save dialog and click the

Save button. To save a setup with the current name, select File | Save.
