TECHNICAL DATA
Performance values refer to the following conditions:
 Sound pressure measured in an 85 m
3
semi-reverberant test
chamber with reverberation time Tr = 0.5s.
Cooling:
- room air temperature 27 °C B.S., 19 °C B.U.;
• maximum speed:
- water inlet temperature 7 °C; ∆t water 5 °C.
• medium and low speed:
- water inlet temperature 7 °C;
- water flow rate remains same as at maximum speed.
Heating:
room air temperature 20 °C B.S.;
• maximum speed:
- water inlet temperature 70 °C; ∆t water 10 °C;
• medium and low speed:
- water inlet temperature 70 °C;
- water flow rate remains same as at maximum speed.
• maximum speed (water inlet 50°C):
- water inlet temperature 50 °C;
- water flow rate same as in cooling operation.
FCX 24 FCX 34 FCX 44 FCX 54 FCX 64 FCX 84
3950 5850 8600 10100 14300 17100
3200 4850 6930 8760 11500 14420
2200 3850 5200 6240 8500 11200
2320 3550 5250 6100 7810 10400
340 503 740 869 1230 1471
4 8 21 22 22 30
1730 2800 4450 4970 6350 8600
1500 2450 3780 4770 5520 7600
1150 2050 2970 3620 4500 6270
1380 2130 3300 3540 5030 5780
1140 1789 2722 3101 4195 5016
828 1441 2079 2281 3330 4013
297 482 765 855 1092 1479
3 9 19,2 25,9 13 22
290 450 600 720 920 1140
220 350 460 600 720 930
140 260 330 400 520 700
1 2 2 2 3 3
42,5 39,5 46,5 47,5 48,5 52,5
37,5 32,5 41,5 44,5 42,5 48,5
26,5 27,5 32,5 35,5 35,5 42,5
51 48 55 56 57 61
46 41 50 53 51 57
35 36 41 44 44 51
1 1,5 1,9 1,9 3,4 3,4
33 44 57 67 91 106
0,25 0,45 0,51 0,36 0,48 0,62
3/4” 3/4” 3/4” 3/4” 3/4” 3/4”
Mod.
Heating
W (max.)
Heating capacity W (med.)
W (min.)
Heating capacity*
W (E)
(water inlet 50°C)
Water flow rate l/h
Water pressure drop kPa
Cooling
W (max.) (E)
Total cooling capacity W (med.)
W (min.)
W (max.) (E)
Sensible cooling capacity W (med.)
W (min.)
Water flow rate l/h
Water pressure drop kPa (E)
m
3
/h (max.)
Air flow rate m
3
/h (med.)
m
3
/h (min.)
Fans n.
dB (A) (max.)
 Sound pressure dB (A) (med.)
dB (A) (min.)
dB (A) (max.) (E)
Sound power dB (A) (med.) (E)
dB (A) (min.) (E)
Water contents l
Max. motor power W (E)
Max. input current A
Coil connections 4R ø
FCX P with 4-row coil
Power supply = 230V ~ 50Hz (E) = EUROVENT certified performance
