C. Open Case Assy (cont)
CLOSE
1. Close the Case Assy.
2. Install four screws (17 in/lbs).
3. Install four screws (17 in/lbs).
2. Install bumpers. Tighten the four captive screws
holding the bumpers (two in back and two in front).
FOLLOW-ON MAINTENANCE
Install Battery (para 2-4A).
END OF TASK
