Subject to Export Control, see Cover Page for details. 2-71
I. LCD Assy (62A1A2A4) (3500 Only)
DESCRIPTION
This procedure covers: Remove. Install.
PRELIMINARY PROCEDURES
Remove Battery (para 2-4A).
Open Case Assy (para 2-4C).
REMOVE
1. Remove the Display Cover.
2. Remove four screws.
3. Remove the LCD PCB Assy
To Next Page
