2-70 Subject to Export Control, see Cover Page for details.
H. Multi-Function PCB Assy (62A1A2A3) (3500A Only) (cont)
INSTALL
1. Install Multi-Function PCB Assy.
2. Install standoff and 10 screws (6 in/lbs.).
3. Connect ribbon cable and Flex Assy
(62A1A2A6),
FOLLOW-ON MAINTENANCE
Install RF Digitizer PCB Assy (para 2-4F).
Install Audio I/O Assy (para 2-4M)
Close Case Assy (para 2-4C).
Install Battery (para 2-4A).
END OF TASK
