Subject to Export Control, see Cover Page for details. 2-73
J. LCD Assy (62A1A2A4) (3500A Only)
DESCRIPTION
This procedure covers: Remove. Install.
PRELIMINARY PROCEDURES
Remove Battery (para 2-4A).
Open Case Assy (para 2-4C).
REMOVE
1. Disconnect wire/ribbon cable, three ribbon
cables and the Flex Assy (62A1A2A6).
2. Remove the Display Cover.
3. Remove four screws.
4. Remove the LCD Assy
To Next Page
