2-74 Subject to Export Control, see Cover Page for details.
J. LCD Assy (62A1A2A4) (3500A Only) (cont)
INSTALL
1. Install the LCD Assy
2. Install four screws (6 in/lbs.).
3. Install the Display Cover.
4. Connect wire/ribbon cable, three ribbon
cables and the Flex Assy (62A1A2A6).
FOLLOW-ON MAINTENANCE
Close Case Assy (para 2-4C).
Install Battery (para 2-4A).
END OF TASK
