14
Installation for use Off-Ventilator
Use with a Face Mask
Mask kits, which include a vented elbow and mask elbow, are available
separately (visit www.aerogen.com for full parts list).
1. When using a mask, connect the vented elbow, mask elbow and mask
to the nebuliser by firmly pushing the parts together.
2. Rotate the vented elbow to suit the position of the patient (Figure 9).
Figure 9. Connecting to a mask
Use with a Mouthpiece
The Aerogen Solo is compatible with any standard ISO 22mm nebuliser
mouthpiece inserted into the adult T-piece.
When using a mouthpiece, connect the nebuliser to the T-piece and
then connect the T-piece to the mouthpiece by pushing the parts firmly
together as shown in Figure 10.
Figure 10. Connecting to a mouthpiece
Patient Upright
