AGA DC5 User Manual

34
18. Technical data
HOTPLATE - Natural Gas Right-hand Front Left-hand Rear Right-hand Rear Left-hand Front
BURNER TYPE
WOK RAPID SEMI - RAPID SEMI - RAPID
MAXIMUM HEAT INPUT
3.5 KW 3.1 KW 1.80 KW 1.80 KW
12.5 MJ/hr 11.2 MJ/hr 6.5 MJ/hr 6.5 MJ/hr
INJECTOR MARKING
170 155 118 120
PRESSURE POINT POSITION: Front left-hand hotplate injector
PRESSURE SETTING:
1 kPa (4” wg)
BURNER IGNITION: H.T. Spark
HOTPLATE - Propane X Right-hand Front Left-hand Rear Right-hand Rear Left-hand Front
BURNER TYPE
WOK RAPID SEMI - RAPID SEMI - RAPID
MAXIMUM HEAT INPUT
13.3 MJ/hr
3.7 KW
(266 g/h)
(0.53 l/h)
11.2 MJ/hr
3.1 KW
(221 g/h)
(0.43 l/h)
6.5 MJ/hr
1.8 KW
(128 g/h)
(0.26 l/h)
6.5 MJ/hr
1.8 KW
(128 g/h)
(0.26 l/h)
INJECTOR SIZE (mm)
1.05 0.94 0.72 0.75
PRESSURE POINT POSITION: Front left-hand hotplate burner injector
PRESSURE SETTING: 2.54 kPa (10” wg)
BURNER IGNITION: H.T. Spark
ELECTRIC GRILL AND OVENS: 240v, 50 Hz, single-phase 30 AMP
GRILL ELEMENT POWER RATING 2 x 1.05 kW (240V)
TOP OVEN POWER RATING 1.0 kw (240V)
LOWER OVEN 1.4 kW (230V) / 1.52 kW (240V)
The data plaque is located in the centre vent slot near the base of the front plate.
Weight of appliance(s)
• AGA Total Control (TC3) = 370 kgs.
• AGA Dual Control = 444 kgs.
• Hotcupboard (TC5 / DC5) = 110 kgs.
• Module = 141 kgs.

AGA DC5 Specifications

General

Brand	AGA
Model	DC5
Category	Ranges
Language	English
