AGD 650 - Technical Specifications; Detailed Specifications

17
AGD 650
DUAL ZONE STOP-LINE DETECTOR
AGD 650
DUAL ZONE STOP-LINE DETECTOR
AGD 650
DUAL ZONE STOP-LINE DETECTOR
AGD 650
DUAL ZONE STOP-LINE DETECTOR
94mm
175mm
217mm
PRODUCT DIMENSIONS
Technical Specifications
SPECIFICATIONS
Description Dual Zone Stop-line Detector
Technology AGD Optical Vision with AI
Detection Zone Dual Virtual Loops
Mounting Height 3-6m Nominal
Power Supply 24/42V ac/dc
Power 12W @ 24Vac (740mA) / 24Vdc (440mA) / 42Vac (530mA)
WiFi Frequency/Power 2412-2472 MHz / Highest EIRP power in the range (dBm): 19.7’
LED Indication LEDs for detect and WiFi connection
Frames per second 7.5
Housing Material Black Polycarbonate / Aluminium
Range 20m at full FOV / 30m at reduced FOV
Sealing IP65
Operating Temp -25°C to +60°C
Configuration WiFi AGD Touch-Setup
Lux Level Operates down to 20 Lux
Dimensions W 217mm x D 94mm x H 175mm
Weight 1200g
Complies with EMC: BS EN 50293:2012, EN 301 489-17, EN 301 489-1
Health & Safety: BS EN 62368, EN 60950-22, EN 50556, EN 62311
Spectrum: EN 300 328
RoHS: EN 50581
Other: TOPAS 2505B
Patent No. Patent Pending
Owing to the Company’s policy of continuous improvement, AGD Systems Limited
reserves the right to change their specification or design without notice.
