58
4454C EN 2013-05-14Re-erasing an image plate
CR 35-X DIGITIZER
When the CR 35-X has erased the image plate, it displays the operator main
screen.
4 Remove the cassette from the cassette slot.
Re-erasing image plates with status ‘to be
erased’
To re-erase an image plate which you have given the status ‘to be erased’ via
the ID station:
1 Check that the CR 35-X is ready for operation:
• The CR 35-X must display the operator main screen with ‘Ready’ status, e.g.:
• The status indicator at the top of the CR 35-X must be green and be lit constantly.
2 Insert the cassette into the cassette slot.
The CR 35-X will automatically erase the image plate. The display will read:
When the CR 35-X has erased the image plate, it displays the operator main screen.
3 Remove the cassette from the cassette slot.
