AGFA DR 14s - Page 104

Warming-up time
30 minutes
Dimensions
Dimensions
width x length x height
approx. 384.5 x 460.5 x 16.0 mm
Weight (incl. battery) 2.8 kg
Maximum total load 135 kg over the whole detector surface
150 kg over the whole detector surface
(image quality of the exposure may not
be optimal)
Maximum load 80 kg on an area of 80 mm in diameter
100 kg on an area of 80 mm in diameter
(image quality of the exposure may not
be optimal)
Vibration tolerance 2 g
Shock tolerance 10 g
SAR value 0.276 W/kg
Throughput (images per hour) 240
DR 14s (CsI conversion
screen)
DR 14s (GOS conversion
screen)
Conversion screen CsI Gadox
Pixel size 148 µm
Active pixel matrix
2400 x 2880
Effective pixel matrix
2330 x 2846
Detector type amorphous silicium
Active area size 355.2 mm x 426.2 mm
Effective area size
344.8 mm x 421.2 mm
104 | DR 14s | Technical Data
0350B EN 20190319 1349 *
