Attaching the Handle Unit with Grid
1
2
CAUTION:
To safely attach the handle unit for making exposures using the
grid, follow these instructions.
1. Lay down the grid on a flat surface.
2. Lay the DR Detector in the grid, bottom edge first, with the tube side
facing down (1).
3. Attach the grid to the DR Detector (2).
WARNING:
Use only the grid that is supplied as option to the DR
Detector.
DR 14s | Getting started | 83
0350B EN 20190319 1349 *
