2. Patient orientation (AP)
3. Result on monitor
Table 3: Chest PA Landscape
Figure 19: Chest PA landscape
1. Detector orientation (Landscape)
2. Patient orientation (PA)
3. Result on monitor
Table 4: Table with bucky
Table with bucky, portrait
Table with bucky, landscape
Note: NX is configured for a specific patient orientation, either
head left (default) or head right.
DR 14s | Getting started | 75
0350B EN 20190319 1349 *
