Installation
Agilent 4107 Nitrogen Generator User’s Guide 17
Installing the Nitrogen Generator
CAUTION
The nitrogen generator may suffer irreparable damage if operated without the
required quality and filtering of the inlet air.
Unpacking
WARNING
Heavy Weight
Danger to feet and hands. The nitrogen generator weighs approximately
110 kg (242.5 lb). To avoid injury to personnel or damage to equipment,
always use a suitable lifting device when moving the instrument.
To unpack the nitrogen generator:
1 Remove the external packaging.
2 Unscrew the four screws attaching the side rails to the pallet on
each side of the nitrogen generator. See ‘Rail to pallet screws’
below.
Figure 2. Location of the screws securing the nitrogen generator to the pallet
Rail to nitrogen generator
screws
Rail to pallet screws
