2-8 Agilent 4155C/4156C VXIplug&play Driver User’s Guide, Edition 4
Driver Function Reference
Parameters
Table 2-4 SMU output voltage, resolution, and compliance by range
Table 2-5 SMU/VMU measurement voltage and resolution by range
Output range
(actually used)
Output voltage
a
a. Parameter name may be base, bias, peak, stress, value, start, stop, and so on.
Setting
resolution
Maximum comp value
b
b. This column shows the maximum value of the current compliance.
HRSMU/
MPSMU
HPSMU
2 V 0 ≤ |V| ≤ 2 V 100 μV ±100 mA ±1000 mA
20 V 0 ≤ |V| ≤ 20 V 1 mV ±100 mA ±1000 mA
40 V 0 ≤ |V| ≤ 20 V 2 mV ±100 mA ±1000 mA
20 V < |V| ≤ 40 V ±50 mA ±500 mA
100 V 0 ≤ |V| ≤ 20 V 5 mV ±100 mA ±1000 mA
20 V < |V| ≤ 40 V ±50 mA ±500 mA
40 V < |V| ≤ 100 V ±20 mA ±125 mA
200 V 0 ≤ |V| ≤ 20 V 10 mV - ±1000 mA
20 V < |V| ≤ 40 V - ±500 mA
40 V < |V| ≤ 100 V - ±125 mA
100 V < |V| ≤ 200 V - ±50 mA
Measurement
range
(actually used)
Measurement
voltage
Measurement resolution
Integration time
High speed
a
sampling
measurement
a. This column is applied to the sampling measurement that initial interval is set to 480 μs or
shorter.
1PLC or
longer
640 μs to
1.92 ms
80 μs to
560 μs
0.2 V (for VMU in
differential mode)
0 ≤ |V| ≤ 0.2 V 0.2 μV2 μV20 μV 200 μV
2 V 0 ≤ |V| ≤ 2.2 V
(2 V for VMU)
2 μV20 μV 200 μV2 mV
20 V 0 ≤ |V| ≤ 22 V
(20 V for VMU)
20 μV 200 μV2 mV 20 mV
40 V 0 ≤ |V| ≤ 44 V 40 μV 400 μV4 mV 40 mV
100 V 0 ≤ |V| ≤ 100 V
(110 V for HPSMU)
100 μV 1 mV 10 mV 100 mV
200 V (for HPSMU) 0 ≤ |V| ≤ 200 V 200 μV 2 mV 20 mV 200 mV
