Agilent 4155C/4156C VXIplug&play Driver User’s Guide, Edition 4 6-37
Programming Examples for VEE Users
Multi-Channel Pulsed Sweep Measurements
Figure 6-32 Program Example of Multi-Channel Pulsed Sweep Measurement
Table 6-21 Program Explanation
Object Title Menu Explanation
VbeStart,VbeStop
MeasPoints
Data-Constant-Real
Data-Constant-Integer
Enters PWV command parameters.
For Count Flow-Repeat-ForCount Repeats next action for specified count.
To/From HP4156B I/O-InstrumentManager-Plug&play Executes measurement, or reads data.
ABS(A) Device-Formula Calculates absolute value of Vbe (source).
Ic,Ib-Vbe Display-XvsYPlot Plots Ic-Vbe and Ib-Vbe curves.
