Agilent 4155C/4156C VXIplug&play Driver User’s Guide, Edition 4 7-33
Sample Application Programs Using VEE
Customizing Sample Programs
5. Open the Pre-Setup object, and delete the sub_ch and Vsub input terminals.
6. Open the Setup 4155 object, and delete the sub_ch and Vsub input terminals.
7. Delete the hp4156b_force(instrHandle,sub_ch,.....) function from the Setup
4155 object.
Figure 7-20 To Remove a Source Output (2)
7.hp4156b_force function for
substrate is deleted.
5.Pre-Setup object is opened.
sub_ch and Vsub are deleted.
6.sub_ch and Vsub are deleted.
To Next Page
