Installation
Agilent 5100 and 5110 ICP-OES User’s Guide 37
Torch disassembly
To disassemble a two piece demountable torch:
You may need a flat head screwdriver to loosen the securing ring if
you cannot gently slide the torch out of the torch body by hand.
CAUTION
Only use the screw driver to loosen the torch securing ring from the torch body if
you are unable to do so by hand.
1 Insert the screwdriver into the slot between the torch securing
ring and the torch body.
2 Gently twist the screwdriver to separate the torch securing ring
from the torch body.
Figure 9. Separating the torch securing ring from the torch body
3 Repeat Steps 1 and 2 on the slot on the opposite side.
4 Gently slide the torch out of the torch body.
Figure 10. Removing the torch from the torch body
