Agilent Technologies 654 A Series Service Manual

108 Replaceable Parts
Table 5-5. Parts List For 200 Watt A1 Main Board for Agilent Models 654xA and 664xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
R583 0698-3160 Resistor 31.6K 1%
R584 0757-0442 Resistor l0K 1% .125W
R585 0757-0419 Resistor 681 1% .125W
R590 0757-0416 Resistor 511 1% .125W
R591 65/6641A, 65/6642A 0757-0280 Resistor 1K 1% .125W
R591 65/6643A 0757-0274 Resistor 1.21K 1%
R591 65/6644A 0698-3153 Resistor 3.83K 1%
R591 65/6645A 0698-3156 Resistor 14.7K 1%
R592 65/6641A, 65/6642A 0757-0280 Resistor 1K 1% .125W
R592 65/6643A 0757-0274 Resistor 1.21K 1%
R592 65/6644A 0698-3153 Resistor 3.83K 1%
R592 65/6645A 0698-3156 Resistor 14.7K 1%
R595 65/6641A 0812-0083 Resistor 40 5% 5W PW
R595 65/6642A 0811-1204 Resistor 200 5% 5W PW
R595 65/6643A 0811-1860 Resistor 600 5% 5W PW
R595 65/6644A 0812-0100 Resistor 2K 5% 5W PW
R595 6645A 0811-1708 Resistor 7K 5% 5W 5W PW
R596 0683-1065 Resistor l0M 5% .25W
R597 0683-1065 Resistor l0M 5% .25W
R601 65/6645A 8159-0005 Resistor Zero Ohms
R605 65/6641A,
65/6643A-65/6645A
8159-0005 Resistor Zero Ohms
R606 65/6641A,
65/6643A-65/6645A
8159-0005 Resistor Zero Ohms
R607 8159-0005 Resistor Zero Ohms
R610 0698-6360 Resistor l0K.1%
R611 0698-6343 Resistor 9K .1% .125W
R612 0757-0442 Resistor l0K 1% .125W
R613 0698-6630 Resistor 20K .1%
R614 0698-3156 Resistor 14.7K 1%
R615 0698-3156 Resistor 14.7K 1%
R616 0683-2255 Resistor 2.2M 5% .25W
R617 0757-0279 Resistor 3.16K 1%
R618 0757-0441 Resistor 8.25K 1%
R619 0698-0082 Resistor 464 1% .125W
R620 0757-0449 Resistor 20K 1% .125W
R621 0757-0449 Resistor 20K 1% .125W
R622 All except 6644A 0699-2246 Resistor 25K .05%
R622 6644A 0699-2248 Resistor 47.5K .05%
R623 6543A 0699-2879 Resistor 80K .05% 5PPM .1W
R623 6544A 0699-2198 Resistor 243K .05%
R623 6641A 0699-3103 Resistor l9K .05%
R623 6642A 0699-2248 Resistor 47.5K .05%
R623 6645A 0699-3104 Resistor 250K .125W
R624 6543A 0698-6614 Resistor 7.5K .1%
R624 6544A 0698-3988 Resistor 42K .1%
R624 6641A 0698-6362 Resistor lK .1% .125W
R624 6642A 0698-6631 Resistor 2.5K .1%
