124 Replaceable Parts
Table 5-7. Parts List For 500 Watt A1 Main Board for 655xA & 665xA (continued)
Reference
Desig.
Applicable Models Agilent Part No. Description
R680 65/6651A 0698-0084 Resistor 2.15K 1%
65/6652A 0757-0283 Resistor 2K 1% .125W
65/6653A, 65/6654A 0757-0280 Resistor 1K 1% .125W
65/6655A 0757-0279 Resistor 3.16K 1%
R681 65/6651A 0698-3162 Resistor 46.4K 1%
65/6652A, 65/6655A 0757-0459 Resistor 56.2K 1%
65/6653A, 65/6654A 0698-3160 Resistor 31.6K 1%
R682 0757-0401 Resistor 100 1% .125W
R683 0698-3160 Resistor 31.6K 1%
R684 0757-0442 Resistor l0K 1% .125W
R685 0757-0419 Resistor 681 1% .125W
R686,687 8159-0005 Resistor 0 Ohms
R690 0698-0082 Resistor 464 1% .125W
R691,692 65/6651A, 65/6652A 0757-0280 Resistor 1K 1% .125W
65/6653A 0757-0274 Resistor 1.21K 1% .125W
65/6654A 0698-3153 Resistor 3.83K 1% .125W
65/6655A 0698-3156 Resistor 14.7K 1% .125W
R693,694 Not used
R695 65/6651A 0811-1899 Resistor 25 5% 10 W
65/6652A 0811-1903 Resistor 100 5% 10 W
65/6653A 0811-0054 Resistor 300 5% 10 W
65/6654A 0811-1586 Resistor 1K 5% 10 W
65/6655A 0811-1873 Resistor 3K 5% 10 W
R696,697 0683-1065 Resistor 10 M 5% .25W
R700,701 0698-3162 Resistor 46.4K 1%
R702 0698-3153 Resistor 3.83K 1%
R703 65/6651A 0757-0443 Resistor 11K 1%
65/6652A 0757-0452 Resistor 27.4K 1%
65/6653A 0757-0457 Resistor 47.5K 1%
65/6654A 0757-0463 Resistor 82.5K 1%
65/6655A 0757-0470 Resistor 162K 1%
R704 0757-0465 Resistor l00K 1%
R705 Resistor 215K 1%
65/6651A 0698-3454
65/6652A-65/6654A 0698-8827 Resistor 1M 1% .125W
65/6655A 0699-0070 Resistor 3.16M 1%
R706 0757-0419 Resistor 681 1% .125W
R707 0757-0401 Resistor 100 1% .125W
R708 0698-0084 Resistor 2.15K 1%
R709 0757-0284 Resistor 150 1% .125W
R710 Not used
R711 0757-0284 Resistor 150 1% .125W
R712 0698-3155 Resistor 4.64K 1%
R713 0698-8827 Resistor 1M 1% .125W
R714 65/6651A 0698-3572 Resistor 60.4K 1%
65/6652A 0757-0452 Resistor 27.4K 1%
65/6653A 0698-8820 Resistor 825K 1%
65/6654A 0698-3260 Resistor 464K 1%
65/6655A 0699-0070 Resistor 3.16M 1%
To Next Page
