130 Replaceable Parts
Table 5-9B. A2 GPIB Board Replaceable Parts for 664xA & 665xA Only (continued)
Ref. Desig. Agilent Part No. Description
J106 1251-4926 Connector receptacle (test header)
J107,108,114,115 1251-7330 Connector receptacle phone
L101 9100-1610 Inductor 150nH 20%
P101 1251-4245 Connector plug 2-pin (ac bias)
Q101 1853-0089 Transistor PNP 2N4917
R103 0757-0442 Resistor 10K 1% 0.125W
R104 0698-3155 Resistor 4.64K 1%
R105 0683-1065 Resistor 10 M 5% 0.25 W
R106 0698-4037
Resistor 46.4Ω 1%
R107 0698-0082
Resistor 464Ω 1% 0.125 W
R108 0757-0401
Resistor 100Ω 1% 0.125 W
R109 0698-0082
Resistor 464Ω 1% 0.125 W
R111,114 0698-3155 Resistor 4.64K 1%
R115-117 0698-4037 Resistor 46.4 1%
R118 0757-0280 Resistor 1K 1% 0.125 W
R119 0698-8827
Resistor 1MΩ 1% 0.125 W
R120-122 0698-3155 Resistor 4.64K 1%
R123 0698-0082
Resistor 464Ω 1% 0.125 W
R130-133 0698-3155 Resistor 4.64K 1%
R134 0683-1015
Resistor 100Ω 5% 0.25 W
R135,136 0698-3155 Resistor 4.64K 1%
R137 0757-0401
Resistor 100Ω 1% 0.125 W
TB101 0360-2312 Terminal block (digital control)
U101 1826-0468 IC MC3423Pl
U106 5080-2152 IC ROM GPIB
U108 1818-4111 IC MCM 6164C55
U109 1820-6789 IC interface
U110,111 1990-0444 IC Opto isolator
U112 1820-3210 IC 68B50
U113 1990-0543 IC Opto isolator
U114 1820-6721 IC MPU
U115 lLH4-0001 IC GPIB transceiver
U116 1820-2724 IC SN74ALS573BN
U117 1820-2549 IC 8291A
U118 1820-4185 IC interface
U119 5080-2153 IC GAL programmed GPIB
U120 5080-2154 IC GAL programmed GPIB
U121 1820-0430 IC LM309K
VR101 1902-0766 Diode zener 18.2V 5%
VR102 1902-0959 Diode zener 11V 5%
VR103,104 1902-0049 Diode zener 6.19V 5%
W101 1258-0209 Jumper
Y101 0410-2109 Crystal oscillator 12.000 MHz
1205-0758 Heatsink (U121)
0340-1277 Insulator (Y101)
0535-0031 Nut hex w/lockwasher (J101)
0515-0642 Screw M 3.5 x 0.6 8 mm lg. pan head (U121)
0515-0911 Screw M 3 x 0.5 12 mm lg. pan head (J101)
1200-0567 Socket IC 28-pin (U106)
1200-0639 Socket IC 20-pin (U119,120)
1200-1274 Socket IC (U114)
