Replaceable Parts 99

Table 5-5. Parts List For 200 Watt A1 Main Board for Agilent Models 654xA and 664xA(continued)

Reference

Desig.

Applicable Models Agilent Part No. Description

C524 65/6641A 0160-5422 Capacitor .047UF 20%

C600 0160-5422 Capacitor .047UF 20%

C602 0180-3298 Capacitor 2200UF 50V

C603 0180-3298 Capacitor 2200UF 50V

C604 0180-4129 Capacitor lUF 35V

C605 0180-0197 Capacitor 2.2UF 20V TA

C606 0180-4129 Capacitor lUF 35V

C610 0160-5469 Capacitor lUF 10% 50V

C611 0160-4808 Capacitor 470PF 5%

C612 0160-4835 Capacitor .lUF 10% 50V

C613 65/6641A 0160-4835 Capacitor .lUF 10% 50V

C613 65/6642A 0160-4834 Capacitor .047UF 10%

C613 65/6643A 0160-5166 Capacitor .015UF 20%

C613 65/6644A, 65/6645A 0160-5409 Capacitor 3000PF 5%

C614 65/6641A 0160-4835 Capacitor .lUF 10% 50V

C614 65/6642A 0160-4834 Capacitor .047UF 10%

C614 65/6643A 0160-5166 Capacitor .015UF 20%

C614 65/6644A, 65/6645A 0160-5409 Capacitor 3000PF 5%

C615 0160-5422 Capacitor .047UF 20%

C616 65/6641A 0160-5422 Capacitor .047UF 20%

C617 65/6641A 0160-5422 Capacitor .047UF 20%

C618 65/6641A 0160-5422 Capacitor .047UF 20%

C619 65/6641A, 65/6643A 0160-4791 Capacitor l0PF 5% l00V

C619 65/6642A 0160-4795 Capacitor 4.7PF

C619 65/6644A, 65/6645A 0160-4789 Capacitor 15PF 5% l00V

C621 0160-482 Capacitor 1200PF 5%

C622 65/6641A, 65/6643A 0160-4791 Capacitor l0PF 5% l00V

C622 65/6642A 0160-4795 Capacitor 4.7PF

C622 65/6644A, 65/6645A 0160-4789 Capacitor 15PF 5% l00V

C623 65/6641A, 65/6642A 0160-4801 Capacitor l00PF 5%

C624 0160-4788 Capacitor 18PF 5% l00V

C640 65/6641A 0160-6827 Capacitor .022UF 400V

C641 65/6641A 0160-0161 Capacitor .0lUF 10%

C642 65/6641A, 65/6642A 0160-4803 Capacitor 68PF 5% 100V

C642 65/6643A-65/6645A 0160-4801 Capacitor l00PF 5%

C643 0160-5422 Capacitor .047UF 20%

C644 0160-5422 Capacitor .047UF 20%

C645 0160-4355 Capacitor .0lUF 10%

C646 65/6641A, 65/6642A 0160-4805 Capacitor 47PF 5% l00V

C646 65/6643A-65/6645A 0160-4814 Capacitor 150PF 5%

C647 65/6643A-65/6645A 0160-4811 Capacitor 270PF 5%

C648 65/6643A-65/6645A 0160-4811 Capacitor 270PF 5%

C671 0160-4791 Capacitor l0PF 5% l00V

C672 0160-4807 Capacitor 33PF 5% l00V

C691 65/6641A-65/6643A 0160-5422 Capacitor .047UF 20%

C691 65/6644A 0160-4834 Capacitor .047UF 10%

C691 65/6645A 0160-0159 Capacitor 6800PF 10%

C692 0160-4355 Capacitor .0lUF 10%

C693 65/6641A 0160-4355 Capacitor .0lUF 10%
