2 – General Information
18
Safety Considerations
This dc source is a Safety Class 1 instrument, which means it has a protective earth terminal. That
terminal must be connected to earth ground through a power source equipped with a ground receptacle.
Refer to the Safety Summary page at the beginning of this guide for general safety information. Before
installation or operation, check the dc source and review this guide for safety warnings and instructions.
Safety warnings for specific procedures are located at appropriate places in the guide.
Options and Accessories
Table 2-1. Options
Option Description
100
100 Vac nominal, 50/60 Hz
120
120 Vac nominal, 50/60 Hz
220
220 Vac nominal, 50/60 Hz
230
230 Vac nominal, 50/60 Hz
020 Front panel output binding posts
760 Isolation and polarity reversal relays (not available on Agilent 6631B)
1CM Rack mount kit (p/n 5062-3974)
1CP Rack mount kit with handles (p/n 5062-3975)
Accessory Rack slide kit (p/n 1494-0060)
0BN Service manual with extra operating manuals
1
Support rails are required when rack mounting units. Use E3663A support rails for Agilent rack cabinets, and
E3664A for non-Agilent rack cabinets.
Table 2-2. Accessories
Item Part Number
GPIB cables
1.0 meter (3.3 ft) 10833A
2.0 meters (6.6 ft) 10833B
4.0 meters (13.2 ft) 10833C
0.5 meters (1.6 ft) 10833D
RS-232 cable 34398A
(9-pin F to 9-pin F, 2.5 meter, null modem/printer cable with
one 9-pin M to 25-pin F adapter
RS-232 adapter kit (contains 4 adapters) 34399A
9-pin M to 25-pin M for pc or printer
9-pin M to 25-pin M for pc or printer
9-pin M to 25-pin M for modem
9-pin M to 9-pin M for modem
