Installation
Inspection
Damage
When you receive your dc source, inspect it for any obvious damage that may have occurred during
shipment. If there is damage, notify the shipping carrier and the nearest Agilent Sales and Support Office
immediately. The list of Agilent Sales and Support Offices is at the back of this guide. Warranty
information is printed in the front of this guide.
Packaging Material
Until you have checked out the dc source, save the shipping carton and packing materials in case the unit
has to be returned. If you return the dc source for service, attach a tag identifying the model number and
the owner. Also include a brief description of the problem.
Items Supplied
The following user-replaceable items are included with your dc source. Some of these items are installed
in the unit.
Table 3-1. Items Supplied
Item Part Number Description
Power Cord contact nearest Agilent
Sales and Support Office
A power cord appropriate for your location.
Digital connector 1252-1488A 4-terminal digital plug that connects to the back of the unit.
Output cover 06624-20007 Safety cover that installs over the output screw terminals.
Terminal block screws N/A 6-32 X 3/8 inch screws.
Line Fuse 2110-0055
2110-0002
F4A for 100/120 Vac operation
F2A for 220/230 Vac operation
Feet 5041-8801 feet for bench mounting
User's Guide 5962-8196 Contains installation, checkout, and front panel information.
Programming Guide 5962-8198 Contains detailed GPIB programming information.
Cleaning
Use a dry cloth or one slightly dampened with water to clean the external case parts. Do not attempt to
clean internally.
WARNING: To prevent electric shock, unplug the unit before cleaning.
