Replacement Procedures
Replacing the G2613A Injector
20 MAR 2000
6. Front location: Turn the injector so that the turret is facing the front of the
GC. Lower the injector until the alignment pin in the base enters the
alignment hole in the injection port cover.
Back location: Turn the injector so the turret faces the left side of the GC.
Lower the injector until the alignment pin in the base enters the alignment
hole in the injection port cover.
7. Check your work:
• The injector must be vertical.
• The alignment pin must be properly seated in the alignment hole.
• The injector feet should touch the injection port cover.
If the injector will not sit upright on the GC, check that the plumbing and
cabling under the injection port cover are properly routed in their channels.
