Agilent Technologies 7683 Service Manual

Replacement Procedures
Replacing the G1926A Bar Code Reader
MAR 2000 21
Replacing the G1926A Bar Code Reader
1. Unplug the old bar code reader cable from the tray. See Figure 6.
Figure 6 Connecting the bar code reader
2. Remove the bar code reader from the tray.
3. Install the new bar code reader. See Figure 7.
Figure 7 Mounting location for the bar code reader
Connect bar code reader
Mounting clips
Bar code reader
