12 7820A GC Installation Manual
7820A GC Installation Guide
Figure 3 Available preswaged tubing
G4332-60004
Use to connect a single supply gas as:
• Inlet carrier gas
• TCD reference and makeup gas
• uECD anode purge and makeup gas
G4331-60003
Use to connect a single supply gas as:
• Inlet carrier gas
• FID, FPD, or NPD makeup gas
FID, FPD, and NPD air and hydrogen must be
supplied through separate tubing.
