Connecting Cables
Connect a GC to an Agilent data system computer using
LAN communications using a LAN cable. See Figure 15
below.
A single communications LAN cable is supplied with the
GC. The switch (or hub) and other cables must be ordered
separately, if needed. See Table 1 and Table 2 for cabling
requirements for other configurations.
Figure 15 Connecting the GC and computer with a hub/switch (shown at left) or a crossover cable
(shown at right).
LAN cable
LAN cable
Computer
GC
LAN hub/switch
Computer
GC
8121-0940
8121-0940
LAN cable 8121-0940
or
Crossover LAN cable 5183-4648
Table 1 Typical IP addresses for an isolated LAN
GC Computer
IP address 192.168.0.26 192.168.0.1
Subnet mask 255.255.255.0 255.255.255.0
