Agilent Technologies 7820A

7820A GC Installation Guide
7820A GC Installation Manual 39
Table 2 Cabling requirements
7820A GC connected to: Required Cable(s) Part number
7693A Automatic Liquid
Sampler
Injector cable G4514-60610
7697A Headspace
Sampler
Remote, 9-pin
male/6-pin connector
G1530-60930
3395B/3396C Integrator Remote, 9 pin/15 pin
Analog, 2 m, 6 pin
03396-61010
G1530-60570
Non-Agilent
Integrator
General purpose analog
signal cable
2 m, 6 pin
G1530-60560
Non-Agilent
data system
General use remote,
9-pin male/spade lugs
(various lengths)
35900-60670 (2
m),
35900-60920 (5
m),
35900-60930
(0.5 m)
LAN Cable, networking CAT 5,
25 feet
Cable, LAN, crossover
8121-0940
5183-4648
