NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
Ref Osc Menu
NNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNNN
10 MHz Freq Standard None
Sets the swept signal generator
to free-run operation, where no
frequency standard is used.
Programming Codes
SCPI:
ROSCillator:SOURce:INTernal
j
EXTernal
j
NONe
Analyzer:
NONE
See Also
Softkeys listed ab ove.
4
RF ON/OFF
5
Function Group
POWER
Menu Map
NONE
Description
This hardkey turns the RF power output on or o. Press
4
RF ON/OFF
5
.
If the yellow LED ab ove the hardkey is o, power is o, and
RF OFF
appears in the message line of the displa
y. Press the key again to
turn on RF power and restore the p ower value last entered.
Programming Codes
SCPI:
POWer:STATeON
j
OFF
j
1
j
0
Analyzer:
RF1 p ower on, RF0 power o.
See Also
4
MOD
5
,
4
POWER LEVEL
5
ROTARY KNOB
Function Group
ENTRY
Menu Map
NONE
Description
The rotary knob is active whenever the entry area is on. It controls
a rotary pulse generator that allo ws analog-type adjustment of the
active entry area. Although the rotary knob has the feel of analog
control, it is actually a digital control that generates 120 pulses p er
revolution.
Programming Codes
NONE
See Also
ARROW KEYS, ENTRY KEYS
\Entry Area" in Chapter 1
R-2 Operating and Programming Reference
