3-75
Function Reference
Save Graphics (Save Setup Panel)
Save Graphics (Save Setup Panel)
Saves graphic data in CGM or GIF format.
The CGM (Computer Graphics Metafile) format is a vector graphics format
that describes pictures and graphical elements in geometric terms.
The GIF (Graphics Interchange format) is a cross platform graphic standard.
GIF formats are commonly used on many different platforms and readable by
many different types of software.
This selection is only valid when saving to the floppy drive.
Key Path Save/Recall > Save Menu > Save Graphics
Remote
Commands
HCOPy:DEVice:LANGuage GIF | CGM
Save Setup
Accesses the setup panel to configure the save settings:
• file name (create a file name automatically or manually)
• network file path
• network file share
• save (all measurement data or trace data only)
• save graphics (save graphics and the graphic format)
• save to (save to a floppy disk or to the internal drive)
• save traces (select trace(s) to save)
