3-77
Function Reference
Save Setup
Note To access the file and printer share softkeys, you must first configure the
network and enter the user share identity/user profile information for remote
shares. The softkeys for file and printer share will then become available for
selection.
Network File Share
Uses the LAN (local area network) to store, recall, or delete data to remote
hard drives. The data can then be accessed and shared among the users and
printed on designated, network printers.
Note To access the file and printer share softkeys, you must first configure the
network and enter the user share identity/user profile information for remote
shares. The softkeys for file and printer share will then become available for
selection.
Save
Saves the measurement data in a binary format (.dat file). This includes the
traces and all measurement conditions. When the file is recalled, the instru-
ment state will be set to the same state as when the file was saved. The
Trace(s) Only option creates an ASCII (.csv) file. When the file is recalled, the
trace data will be displayed under the current instrument settings.
Save Graphics
Allows you to save graphic data in one of two formats.
CGM (Computer Graphics Metafile format), is a vector graphics format that
describes pictures and graphical elements in geometric terms. The file is
saved with a .cgm extension. This selection is valid only when saving to the
floppy drive.
GIF (Graphics Interchange format), is a cross-platform graphic standard.
GIF formats are commonly used on many different platforms and readable
by many different kinds of software. The file is saved with a .gif extension.
GIF supports up to 8-bit color (256 colors).
Save to
Selects saving data to a floppy disk or to internal memory.
Save Traces
Selects the traces to be saved.
To Next Page
