2-3
Using the Instrument
Setting Up Measurements
Adjusting Setup Conditions
Setup panels allow you to adjust setup conditions which are not frequently
changed. Refer to “Preset” on page 3-65.
Using the softkeys
Arrows allow you to navigate from field to field in the dialog box. The high-
lighted parameter can be changed. The front-panel number keys, step keys,
and knob allows the user to enter a numeric value in the highlighted field.
Select selects the highlighted parameter. You can enter values for a selected
parameter using the front panel knob or numeric entry pad.
Defaults resets the parameters to their default condition.
Close Panel saves the current setup and returns you to the previous menu.
